Case History
On February 10, 2015, our long-term South AfricanY required lightning impulse tests for their transformers. Nanao Electric successfully delivered a 900 kV impulse voltage generator within 20 days.

NAIVG Compliance Standards:

• JB/T 9641-1999 Test Transformers

• DL/T 848.5-2004 General Engineering Factors for High Voltage Test Equipment - Part 5: Impulse Potential Generators

• GB 311.1-1997 Insulation Coordination for High Voltage Power Transformer Equipment

• GB/T 16927.1-1997 High Voltage Test Techniques - General Test Requirements

• GB/T 16927.2-1997 Voltage Test Techniques - Measuring Systems*

• GB/T 16896.1-1997 Digital Recorders for High-Voltage Impulse Tests - Packaging & Transportation

• ZB F24 001-90 Implementation Code for Impulse Potential Measurement

• GB 4208 Ingress Protection (IP) Ratings

• GB 813-89 Application of Oscilloscopes & Peak Meters in Impulse Testing

Software Interface:
NAIVG-DIMS3000B Cross-Section Measurement, Recording & Analysis Software Interface

Key translation choices:

1. Maintained Chinese standard codes with official English titles

2. Used proper hyphenation in technical terms (e.g., "Impulse Potential Generators")

3. Standardized measurement units (900 kV with space separation)

4. Kept software model name intact (NAIVG-DIMS3000B)

5. Applied consistent capitalization in standard references

Would you like me to refine any specific technical terminology

Certification Compliance
Full adherence to ISO 9001:2000 International Quality Management System.

Delivery Checklist

1. NAIVG-900kV/45k
   Automatic Lightning Impulse Voltage Generator Unit

2. NACR-900kV/500pF
   Low-Inductance Lightning Impulse Capacitive Divider

3. NAIVG2017
   Computerized Impulse Voltage Test Control System

4. NAIMS-3000B
   Fully Automated Impulse Measurement & Analysis System

5. NANAO Series
   Modulating Resistor Kit with Grounding Rods

6. NALGR-100kV/100mA-10kVA
   Auto-Rectifying Charging Power Supply

7. NADF-400G
   Single-Sphere Interrupting Discharge Assembly

8. NAFRS-10kA/±1.0%
   Precision Current Shunt with Digital Display

Delivered to PTY Transformer Testing Site, South Africa
